FA Series Diamond Tip Files
(Flexible)
FEATURE
FAS-120 Diamond Tip Files
With the maximum thickness of 1mm only, the files are suitable for narrow and deep gap processing. Contoured to make difficult-to-reach areas readily accessible. They are tapered in thickness to make possible perfectly flat filing and flexible for bending while still maintaining their hardness. Both suitable for hand-held and machine-mounted operations.
FAS-600 Diamond Tip Files
Less material usage. Brand-new manufacturing process provides a better cutting ability and also prolongs the tool life. Both suitable for hand-held and machine-mounted operations. The designation is complied with the ergonomic. Be able to replace the general diamond tapered hand files.
FAS-120 Diamond Tip Files
Unit : mm
L | T | Cross-section | Grit size | Order no. | |
---|---|---|---|---|---|
60 | 25 | #150 #200 #400 |
★FA-426J ★FA-426F FA-426V |
||
60 | 25 | #150 #200 #400 |
★FA-446J ★FA-446F FA-446V |
||
70 | 40 | #150 #200 #400 |
★FA-667J ★FA-667F FA-667V |
||
70 | 40 | #150 #200 #400 |
FA-887J FA-887F FA-887V |
||
90 | 60 | #150 #200 #400 |
★FA-889J ★FA-889F FA-889V |
||
70 | 40 | #150 #200 #400 |
FA-107J FA-107F FA-107V |
||
90 | 60 | #150 #200 #400 |
★FA-109J ★FA-109F FA-109V |
||
60 | 25 | #200 #400 #600 |
FA-326F FA-326V FA-326X |
||
60 | 25 | #200 #400 #600 |
FA-436F FA-436V FA-436X |
||
70 | 40 | #200 #400 #600 |
FA-327F FA-327V FA-327X |
||
70 | 40 | #200 #400 #600 |
FA-437F FA-437V FA-437X |
||
(122) | XH-12 | ||||
10pcs. Set with tool holder / wooden case, containing one each of file which denoted by asterisk and one tool holder (XH-12) |
FAS-600 Diamond Tip Files
Unit : mm
L | T | Cross-section | Grit size | Order no. | |
---|---|---|---|---|---|
70 | 40 | #150 #200 #400 #600 |
FA-632J ★FA-632F ★FA-632V ★FA-632X |
||
80 | 50 | #150 #200 #400 #600 |
★FA-643J ★FA-643F ★FA-643V FA-643X |
||
90 | 50 | #150 #200 #400 #600 |
★FA-666J ★FA-666F FA-666V FA-666X |
||
90 | 50 | #150 #200 #400 #600 |
★FA-688J ★FA-688F FA-688V FA-688X |
||
(122) | XH-32 | ||||
10pcs. Assortment set / pvc pouch, containing one each of file which denoted by asterisk. (Tool holder is optional.) |
FAS-100T
10pcs/set in wooden case.
Containing one each of file which denoted by ★ and one Tool Holder. (XH-12)
10pcs/set in wooden case.
Containing one each of file which denoted by ★ and one Tool Holder. (XH-12)
FAS-600
10pcs/set in PVC pouch.
Containing one each of file which denoted by ★.
(Tool Holder is optional)
10pcs/set in PVC pouch.
Containing one each of file which denoted by ★.
(Tool Holder is optional)
